RAVENOL Turbo Oil T32
is a high quality lubricating oil for gas and steam turbines as well as for turbo compressors with and without gears, which meets the requirements of DIN 51515-2.
RAVENOL Turbo Oil T32
is based on high quality base oils with additives to improve the corrosion protection and resistance to aging.
RAVENOL Turbo Oil T32
is an all-purpose oil for turbines from specially selected base oils with the addition of special refined additives.
Application Note
RAVENOL Turbo Oil T3
is used in stationary gas turbines, steam turbines and also in electrical or in driven by steam machines, such as generators, compressors, pumps and gearboxes.
RAVENOL Turbo Oil T3
is also for use in lubrication of hydraulic systems, compressors, gear transmissions and bearings.
Բնութագրերը
| Կարգավորում | Արժեք | Աուդիտ |
|---|---|---|
| Օդի բացթողում 50 °C ջերմաստիճանում, մաքս., min. | 3 | DIN ISO 9120 |
| Copper strip corrosion | pass | DIN EN ISO 2160 |
| FZG Pass Load Stage | 10 | DIN ISO 14635-1 |
| Լայնությունը, mm | 580 | |
| Purity grade | 19/16/13 | ISO 4406 |
| Time to collapse of the foam at 25 °C, s | 245 | ISO 6247 |
| Foam Volume at 25 °C, ml | 60 | ISO 6247 |
| NZ Neutralisation number, mg KOH/g | 0.06 | DIN 51558-1 |
| Երկարություն, mm | 580 | |
| Water Separability, s | 35 | DIN 51589-1 |
| Բարձրություն, mm | 885 | |
| Քաշը, kg | 191.509 | |
| Brand | RAVENOL | |
| SAE | 32W | |
| Density at 20 °C, kg/m³ | 849 | EN ISO 12185 |
| Գույն | L1.5 | DIN ISO 2049 |
| Մածուցիկություն 100 °C-ում, mm²/s | 5.8 | DIN 51562-1 |
| Մածուցիկություն 40 °C-ում, mm²/s | 32.1 | DIN 51562-1 |
| Viscosity Index VI | 122 | DIN ISO 2909 |
| Pourpoint, °C | < -12 | DIN ISO 3016 |
| Flashpoint, °C | 232 | DIN EN ISO 2592 |
| Water content, mg/kg | < 0.01 | DIN 51777-1 |
