RAVENOL Scheibenfrostschutz Konzentrat is a winter screenwash antifreeze concentrate with a special pleasant citrus perfume, based on alcohols.
RAVENOL Scheibenfrostschutz Konzentrat for the windscreen washing installation protects against icing, keeps the windscreen free of ice, is environment-friendly, cleans intensively and offers a clear sight in traffic during the winter months.
Application Note
RAVENOL Scheibenfrostschutz Konzentrat is mixed with water according to the following mixing table. Make sure the water and concentrate are well mixed. After filling with the windscreen antifreeze, operate the windscreen washing installation, so that the lines up to the spray nozzle are free ofwater.
Concentrate Substance ----- Water ----- Freezing protecton to approx.
2 parts -------- 1 part ------- -30 °C
1 part --------- 1 part ------- -20 °C
1 part --------- 2 parts ------- -10 °C
Characteristics
- A very good cleaning performance
- Material compatibility
- antifreeze without dilution has a freeze protection to -60°C
- Suitable for polycarbonate windscreens
- Lacquer compatibility
- Suitability for use in fan
- Compatible for wipers, plastics and polymers
- Free of methanol
Բնութագրերը
| Կարգավորում | Արժեք | Աուդիտ |
|---|---|---|
| Լայնությունը, mm | 120 | |
| Երկարություն, mm | 200 | |
| Բարձրություն, mm | 330 | |
| Քաշը, kg | 4.698 | |
| Brand | RAVENOL | |
| Density at 20 °C, kg/m³ | 923 | EN ISO 12185 |
| Գույն | Blue | տեսողական |
| Odour | citrus | GERUCH |
| Flashpoint, °C | 23.5 | DIN EN ISO 13736 |
| Freezing point (mixture 2:1), °C | -30 | ASTM D1177 |
| Freezing point (mixture 1:2), °C | -10 | ASTM D1177 |
| Freezing point (mixture 1:1), °C | -20 | ASTM D1177 |
| BMW | 83122298206 |
| BMW | 83122298207 |
| Ford | 1760076 |
| Mercedes-Benz | A002986147117 |
| Mercedes-Benz | A002986147118 |
| Renault | 7711546767 |
| Suzuki | 990LM00690004 |
| Suzuki | 990LM01120001 |
| Volkswagen | G052164M1 |
| Volkswagen | G052164M2 |
| Volkswagen | G052164M6 |
| Volkswagen | G052164M9 |
| Volkswagen Group | G070164M4 |
