RAVENOL Multi ATF LVS Fluid is a synthetic multi-function automatic transmission oil ATF based on highly developed synthesis technology for longest change intervals for automatic transmissions and manual transmissions, in torque converters and numerous power steering systems.
RAVENOL Multi ATF LVS Fluid is suitable for maximum change intervals in automatic transmissions, steering and clutch systems, hydraulics and power take-offs of cars and commercial vehicles when oil with low viscosity is requirred.
Application Note
RAVENOL Multi ATF LVS Fluid is a product with a very wide manufacturer coverage and can be used in almost all conventional automatic transmissions with shift groups.
Not suitable for CVT automatic transmissions.
RAVENOL Multi ATF LVS Fluid can be used as a refill oil in a wide range of applications to meet the requirements of Ford, GM, Toyota, Honda, Nissan, Hyundai, KIA, BMW, Mercedes, Volvo, VW, Audi and others. It will be used if no suitable original oil or RAVENOL Professional Line oil is available.
Observe the manufacturer's instructions.
Characteristics
- Very good lubricity even at low temperatures in winter
- A high, stable viscosity index
- Very low pour point
- Very good oxidation stability
- Protection against wear, corrosion and foaming
- Well-coordinated friction properties
- Neutral behavior towards sealing materials
- Neutral behavior due to inhibition against non-ferrous metals
Բնութագրերը
| Կարգավորում | Արժեք | Աուդիտ |
|---|---|---|
| Լայնությունը, mm | 205 | |
| Երկարություն, mm | 340 | |
| Բարձրություն, mm | 395 | |
| Brand | RAVENOL | |
| Suitable for | Chrysler, Honda Ultra 4WD Rear, SsangYong DSI M11 6-Speed, SsangYong DSI M78 6-Speed | |
| Compliant products | Honda DPSF, Hyundai SP-IV, Hyundai SPH-IV, MB A 001 989 45 03 10, Mitsubishi 4031610, Mopar ZF 8 & 9 Speed ATF, Nissan 999MP-MTS00P, SsangYong Caltex, Volvo 31256774, Volvo 31256775, Volvo 31256776 | |
| Density at 20 °C | 848 | EN ISO 12185 |
| Գույն | Red | տեսողական |
| Viscosity at 100 °C | 5.9 | DIN 51562-1 |
| Viscosity at 40 °C | 29.8 | DIN 51562-1 |
| Viscosity Index VI | 149 | DIN ISO 2909 |
| Brookfield Viscosity at -40 °C, mPa*s | 12050 | ASTM D2983 |
| Pourpoint, °C | -51 | DIN ISO 3016 |
| Flashpoint, °C | 220 | DIN EN ISO 2592 |
| Copper Strip Test at 121 °C | 1b | ASTM D130 |
| Քաշը, kg | 17.779 |
| Aisin | ATF6004 |
| Aisin | ATF6020 |
| Aisin | ATF6200 |
| Chrysler | 68333663AA |
| Chrysler | 68333664AA |
| General Motors | 19315204 |
| General Motors | 19315205 |
| General Motors | 19315206 |
| General Motors | 19315207 |
| General Motors | 88864059 |
| Hyundai XTeer | 1011411 |
| Hyundai XTeer | 1011412 |
| Hyundai XTeer | 1011414 |
| Hyundai XTeer | 1041411 |
| Hyundai XTeer | 1041412 |
| Hyundai XTeer | 1041414 |
| Mazda | 830077TLU007 |
| Mazda | K020W0046M |
| Suzuki | 9900022810000 |
