RAVENOL Getriebeoel EPX SAE 85W-140 GL-5 is a lubricating oil for mechanical gears based on high quality and solvent refined base oils. Special extreme pressure (EP)-active substances and selected additives give excellent lubricating oil properties.
RAVENOL Getriebeoel EPX SAE 85W-140 GL-5 is designed for use with maximum duty, hypoid gearing gears (axel drive, manual transmission, etc.), so far extreme pressure gear oils are required.
Application Note
RAVENOL Getriebeoel EPX SAE 85W-140 GL-5 is designed for use in highly loaded, hypoid gears for hypoid gearbox, as well as for axle, transfer case, transmission gear, auxiliary gearboxes in vehicles and machinery and for use as extreme pressure gear oil where this grade of lubricant is specified by the manufacturer.
Characteristics
- a very good oxidation stability
- widest possible protection against rust and corrosion
- no foam formation
- excellent extreme pressure properties
- low pour point
- neutral behaviour towards metals and sealing materials
Բնութագրերը
| Կարգավորում | Արժեք | Աուդիտ |
|---|---|---|
| Brand | RAVENOL | |
| SAE | 85W-140 | |
| Suitable for | GM | |
| Density at 20 °C, kg/m³ | 894 | EN ISO 12185 |
| Գույն | Brown | տեսողական |
| Մածուցիկություն 100 °C-ում, mm²/s | 26.4 | DIN 51562-1 |
| Մածուցիկություն 40 °C-ում, mm²/s | 355 | DIN 51562-1 |
| Viscosity Index VI | 99 | DIN ISO 2909 |
| Brookfield Viscosity at -12 °C, mPa*s | 55.000 | ASTM D2983 |
| Pourpoint, °C | -24 | DIN ISO 3016 |
| Flashpoint, °C | 224 | DIN EN ISO 2592 |
| Copper Strip Test at 121 °C | 1b | ASTM D130 |
| Երկարություն, mm | 400 | |
| Լայնությունը, mm | 400 | |
| Բարձրություն, mm | 885 | |
| Քաշը, kg | 206.693 |
| Alpine | 0100781 |
| Alpine | 0100783 |
| Alpine | 0100784 |
| Alpine | 0100785 |
| Alpine | 100781 |
| Alpine | 100783 |
| Alpine | 100784 |
| Alpine | 100785 |
| DAF | 1660042 |
| DAF | 1660043 |
| DAF | 1660044 |
| DAF | 1678855 |
| DAF | 1697549 |
| DAF | 1699595 |
| DAF | 1699595G |
| DAF | 1732360 |
| General Motors | 89021799 |
| Hyundai Motor | 0220000420 |
| Hyundai XTeer | 1041432 |
| Scania | 1892412 |
| Scania | 1892413 |
| Scania | 1892414 |
| Scania | 1892415 |
| Scania | 1892416 |
| Volvo | 1161279 |
| Volvo | 1161936 |
| Volvo | 1161937 |
