RAVENOL BIO-Hydraulikoel HEES 46 is based on synthetic, easily biodegradable unsaturated esters and a powerful, environmentally friendly combination of additives which gives the product excellent properties regarding oxidation stability, corrosion, low temperatures as well as EP behaviour.
Compared with products of vegetable triglyceride base, RAVENOL BIO-Hydraulikoel HEES 46 has much better high temperature oxidation stability.
RAVENOL BIO-Hydraulikoel HEES 46 can be used year-round due to its outstanding low-temperature behavior and provides excellent wear and corrosion protection.
Application Note
RAVENOL BIO-Hydraulikoel HEES 46 is used wherever there is the danger of hydraulic fluidleaking into the ground or waste water. This includes all equipment operating in or near areas ofwater purification or water protection or near surface water, such as e.g. sewage treatment plants, dredging ships and floating dredges, lock hydraulics and river weirs, pipe and tunnel diving machines, - hydraulic aggregates in forests and on plains, earth moving machines in water collecting areas, forestry machines.
Characteristics
- Biodegradability
- Excellent corrosion protection
- Outstanding cold behavior
- Excellent oxidation stability
Բնութագրերը
| Կարգավորում | Արժեք | Աուդիտ |
|---|---|---|
| Լայնությունը, mm | 580 | |
| Երկարություն, mm | 580 | |
| Բարձրություն, mm | 885 | |
| Քաշը, kg | 208.981 | |
| SAE | 46 | |
| Brand | RAVENOL | |
| Density at 20 °C, kg/m³ | 917 | EN ISO 12185 |
| Գույն | Yellow | տեսողական |
| Մածուցիկություն 100 °C-ում, mm²/s | 9.45 | DIN 51562-1 |
| Մածուցիկություն 40 °C-ում, mm²/s | 46 | DIN 51562-1 |
| Viscosity Index VI | 190 | DIN ISO 2909 |
| Pourpoint, °C | -36 | DIN ISO 3016 |
| Flashpoint, °C | 296 | DIN EN ISO 2592 |
| Seq. I at 24 °C, ml/ml | 10/0 | ASTM D892 |
| Seq. II at 93,5 °C, ml/ml | 5/0 | ASTM D892 |
| Seq. III at 24 °C after 93,5 °C, ml/ml | 10/0 | ASTM D892 |
| Copper Strip Test at 121 °C | 1a | ASTM D130 |
| Օդի բացթողում 50 °C ջերմաստիճանում, մաքս., min. | 2 | DIN ISO 9120 |
